Documentation 8.7

The rule properties panel of an element opens when clicking the icon MPA-IconoRegla of its context menu.





ME-RepetidorItem-Reglas

Properties



Rules

Embedded rules on behavior, validation and calculation can be defined, associated with an element, by using the wizard (ctrl + space).

65S4_img6 Shows syntax examples for writing the rules.



65S4_v2_img9

Visible

Indicates whether the element is visible. If this property is not checked, the element is not displayed in the page.
toggles_img1  Visible (default)   toggles_img3 Not visible

65S4_img11 Opens an edit area where a rule to determine the visibility condition can be defined. If a rule is defined, the icon is displayed with light blue borders.





Operations when defining the rule:



icon-mod-proc-jxxf3489fhdj

Saves the new or modified rule

icon-mod-proc-d6f4xxx6dfhjfdj

Cancels the operation



Operations once the rule is defined:



icon-mod-proc-xxcf5hfs89fhdj

Edits the existing rule

iconoTACHO_AZUL

Deletes the rule

Events



Items allow the use of different events.





Event

Description

onMouseIn()

It is executed when the cursor is positioned on the element.

onMouseOut()

It is executed when the cursor moves out of the element.

onClick()

It is executed when clicking on the element.

onDoubleClick()

It is executed when clicking twice on the element.

onInit()

It is executed before the element is loaded.

afterViewInit()

It is executed after viewing the element.

onViewportEnter()

It is executed when the element is visible.

onViewportLeave()

It is executed when the element is no longer visible.
