Requirements
The following are the software requirements for the use and installation of Deyel.
Workstations (Cloud and On-Premise Modality)
HARDWARE |
RAM |
a minimum of 4 GB |
|
Screen resolution |
•End user: a minimum of 1024x768 •Modeler: a minimum of 1920x1080 |
SOFTWARE |
Browser |
•Chrome, a minimum of 79.0 •Edge Chromium, a minimum of 79.0 •Firefox, a minimum of 74.0 •Safari 13.1.3 and 14.1.2 (Only for User Portal) |
It is advisable to keep browser versions up-to-date, since security vulnerabilities are regularly corrected.
Application Server (On-Premise Modality)
HARDWARE |
RAM |
a minimum of 6 GB |
|
HD |
a minimum of 5 GB free space. |
|
Processor |
64-bit / 2 cores / at least 2.4GHz |
SOFTWARE |
Web Service |
•WebSphere 8 / WebSphere 9 •Apache Tomcat 8 / Apache Tomcat 9 |
|
Java |
Java 11 |
Database Server (On-Premise Modality)
HARDWARE |
RAM |
a minimum of 4 GB |
|
HD |
a minimum of 10 GB free space |
|
Processor |
64-bit / 2 cores / a minimum of 2.4GHz |
SOFTWARE |
Database |
•Mysql 8 •DB2 9.5 or DB2 10.5 •Sql Server 2012 •Oracle 12c release 12.2 / Oracle 19c |
